ROBO ALDL1576 Recessed adjustable spotlight trimless recessed downlight

ALDL1576

CRI
Ra≥92
Beam angle
15°/24°/36°/60°
CCT
2700K/3000K/4000K

  • TEXTURE WHITE

  • TEXTURE BLACK

Share
Technical Parameter
  • General informatio
    INSTALLATION
    Ceiling Recessed
    Adjustability
    0° to 23° swiveling, 350° rotatable
    Material
    Aluminum Alloy
    Color temperature
    2700K/3000K/4000K
    Beam angle
    15°/24°/36°/60°
    Optics
    Lens
    IP
    IP20
    Warranty(Year)
    5-Year
  • Photometric Result
    Light source
    COB
    Luminous flux
    580lm
    CRI
    Ra≥92
    UGR
    <12
    LED Qty
    1
    Ene Class
    F
    LM80
    L90B10>50000
    McAdam
    SDCM 3
  • Electrical Specifications
    Power
    7W
    Input current
    350mA
    Power supply
    LED power supply 350mA-Max.19V
    Class
    III
  • Dimensions
    Cutout
    ø76-ø80mm
    Thickness of mounting surface
    2-38mm
    Recessed Depth
    60mm
